1.9 TDI Turbocharger Genuine Garrett - 454231-5010S for Audi, Skoda and VW
Genuine new turbocharger from Garrett GT1749V | 454231-5010S including actuator and studs.
SSL protected Data transmission
Fast and reliable delivery
Return deliveries within 14 days
GT1749V | 454231-5010S
Available automotive industry partnumbers (OE-Numbers):
028145702RV225
028 145 702RV225
028 145 702 RV 225
028145702RV500
028 145 702RV500
028 145 702 RV 500
028145702RV550
028 145 702RV550
028 145 702 RV 550
028145702L
028 145 702L
028 145 702 L
028145702LV
028 145 702LV
028 145 702 LV
028145702LX
028 145 702LX
028 145 702 LX
028145702H
028 145 702H
028 145 702 H
028145702HV
028 145 702HV
028 145 702 HV
028145702HX
028 145 702HX
028 145 702 HX
028145702R
028 145 702R
028 145 702 R
028145702RV
028 145 702RV
028 145 702 RV
028145702RX
028 145 702RX
028 145 702 RX
035145702H
035 145 702H
035 145 702 H
035145702HV
035 145 702HV
035 145 702 HV
035145702HX
035 145 702HX
035 145 702 HX
035145702K
035 145 702K
035 145 702 K
035145702KV
035 145 702KV
035 145 702 KV
035145702KX
035 145 702KX
035 145 702 KX
038145702H
038 145 702H
038 145 702 H
038145702HV
038 145 702HV
038 145 702 HV
038145702HX
038 145 702HX
038 145 702 HX
038145702K
038 145 702K
038 145 702 K
038145702KV
038 145 702KV
038 145 702 KV
038145702KX
038 145 702KX
038 145 702 KX
This turbocharger is meant to replace the following previous models (OEM-Numbers):
GT1749V, 4542310002, 4542310006, 4542310008, 4542310009, 4542310010, 454231-0002, 454231-0006, 454231-0008, 454231-0009, 454231-0010, 4542315009S, 454231-5009S, 4542315010S, 454231-5010S, 454231-2, 454231-9, 454231-6, 454231-8, 454231-10
Compatible vehicle models:
| Brand - Vehicle - Engine | Production | kW | hp |
| AUDI - A4 (8D2, B5) - 1.9 TDI | 01.95-11.00 | 66 | 90 |
| AUDI - A4 (8D2, B5) - 1.9 TDI | 10.95-11.00 | 81 | 110 |
| AUDI - A4 (8D2, B5) - 1.9 TDI quattro | 09.96-11.00 | 81 | 110 |
| AUDI - A4 (8D2, B5) - 1.9 TDI | 03.00-11.00 | 85 | 116 |
| AUDI - A4 (8D2, B5) - 1.9 TDI quattro | 03.00-11.00 | 85 | 116 |
| AUDI - A4 Avant (8D5, B5) - 1.9 TDI | 02.96-09.01 | 66 | 90 |
| AUDI - A4 Avant (8D5, B5) - 1.9 TDI | 02.96-09.01 | 81 | 110 |
| AUDI - A4 Avant (8D5, B5) - 1.9 TDI quattro | 09.96-09.01 | 81 | 110 |
| AUDI - A4 Avant (8D5, B5) - 1.9 TDI quattro | 09.96-09.01 | 81 | 110 |
| AUDI - A4 Avant (8D5, B5) - 1.9 TDI | 03.00-09.01 | 85 | 115 |
| AUDI - A4 Avant (8D5, B5) - 1.9 TDI quattro | 03.00-09.01 | 85 | 115 |
| AUDI - A4 (8E2, B6) - 1.9 TDI | 05.01-12.04 | 74 | 101 |
| AUDI - A4 (8E2, B6) - 1.9 TDI | 06.04-12.04 | 85 | 116 |
| AUDI - A4 Avant (8E5, B6) - 1.9 TDI | 11.01-12.04 | 74 | 101 |
| AUDI - A4 Avant (8E5, B6) - 1.9 TDI | 06.04-12.04 | 85 | 116 |
| AUDI - A4 (8EC, B7) - 1.9 TDI | 11.04-06.08 | 85 | 116 |
| AUDI - A4 Avant (8ED, B7) - 1.9 TDI | 11.04-06.08 | 85 | 116 |
| AUDI - A6 (4B, C5) - 1.9 TDI | 04.97-10.00 | 81 | 110 |
| AUDI - A6 (4B, C5) - 1.9 TDI | 07.00-01.05 | 85 | 115 |
| AUDI - A6 Avant (4B, C5) - 1.9 TDI | 02.98-04.01 | 81 | 110 |
| AUDI - A6 Avant (4B, C5) - 1.9 TDI | 07.00-01.05 | 85 | 115 |
| SKODA - SUPERB (3U4) - 1.9 TDI | 08.02-10.05 | 74 | 101 |
| VW - PASSAT (3B2) - 1.9 TDI | 10.96-11.00 | 66 | 90 |
| VW - PASSAT (3B2) - 1.9 TDI | 02.00-11.00 | 74 | 101 |
| VW - PASSAT (3B2) - 1.9 TDI | 10.96-11.00 | 81 | 110 |
| VW - PASSAT (3B2) - 1.9 TDI Syncro/4motion | 10.96-11.00 | 81 | 110 |
| VW - PASSAT (3B2) - 1.9 TDI | 08.98-11.00 | 85 | 115 |
| VW - PASSAT (3B2) - 1.9 TDI 4motion | 08.99-11.00 | 85 | 115 |
| VW - PASSAT Variant (3B5) - 1.9 TDI | 06.97-11.00 | 66 | 90 |
| VW - PASSAT Variant (3B5) - 1.9 TDI | 02.00-11.00 | 74 | 101 |
| VW - PASSAT Variant (3B5) - 1.9 TDI | 06.97-11.00 | 81 | 110 |
| VW - PASSAT Variant (3B5) - 1.9 TDI Syncro/4motion | 06.97-11.00 | 81 | 110 |
| VW - PASSAT Variant (3B5) - 1.9 TDI | 08.98-11.00 | 85 | 115 |
| VW - PASSAT Variant (3B5) - 1.9 TDI 4motion | 08.99-11.00 | 85 | 115 |
| VW - PASSAT (3B3) - 1.9 TDI | 11.00-05.05 | 74 | 101 |
| VW - PASSAT Variant (3B6) - 1.9 TDI | 11.00-05.05 | 74 | 101 |
| Motorcode - Manufacturer | kW | hp |
| AHU | ||
| AJM | ||
| ATJ | ||
| AUY | ||
| AVB | ||
| AVG | ||
| BKE |
Exclusive Genuine
(only genuine parts of the mentioned brand supplier. NO CHEAP ASIA-COPIES!)
Exclusive Brand new products
(no intertreatment, no reconditioning, NOT USED! We offer solely new genuine parts.)
Always Customer-focused
(Customer-friendly secure handling, without compromises. We are happy to look for and identify the right turbocharger for your car. Additionaly if you run your own business you will receive special conditions.)
Of course NO DEPOSITS!
*) The content of OE, OEM numbers and item numbers are assigned only to technical data and applications. They are not related to a claim for equality, for example in terms of origin, material properties or durability. All data without guarantee.
454231-5010S
Specific References
Accessories
Genuine new turbocharger from Garrett GT1749V | 454231-5010S including actuator and studs.
